MA Lighting grandMA2 onPC Command Wing

This MA Lighting grandMA2 onPC Command Wing shows signs of wear, but it has been tested and is in good working condition.

The MA Lighting grandMA2 onPC Command Wing paves the way for mobile use of the highly flexible and powerful grandMA2 control system. In combination with the free of charge grandMA2 onPC software, it delivers real-time control for 2,048 parameters, making it a compact solution for programming and playback in venues, tours, studios, and temporary event setups where a full console is not practical. It offers two built-in DMX ports as well as the possibilty to send two additional DMX universes via Ethernet.

Designed for a grandMA2-style Workflow

Built around a command section similar to the grandMA2 layout, the Command Wing helps operators keep familiar muscle memory when moving between onPC and full grandMA2 systems. Two A/B faders (100mm) support hands-on playback control, and the dedicated Level-Wheel provides fast, precise adjustments during programming and live operation.

Connectivity and Expandability

For straightforward deployment, the wing connects via USB to any PC running grandMA2 onPC. It is expandable up to 4,096 parameter, and supports up to 65,536 parameters as backup in the MA system, which is useful when integrating into larger grandMA2 environments.

Built for Transport and Daily Use

Individually backlit and dimmable silent (clickless) keys improve visibility in dark control environments while keeping operation quiet. An integrated universal power supply (90-240V, 50-60Hz) supports reliable use across different power standards. The unit is light (just 6kg), handy, and rock solid, with an ergonomic design sized for mobile rigs (536 x 395 x 70mm / 21.1 x 15.6 x 2.8inch).

• 2,048 parameter real-time control with grandMA2 onPC
• Expandable up to 4,096 parameter
• 2 built-in DMX ports, plus 2 additional DMX universes via Ethernet
• Command section similar to grandMA2 layout
• 2 A/B faders (100mm), 1 Level-Wheel
• Individually backlit, dimmable silent keys
• Universal power supply (90-240V, 50-60Hz)
• Dimensions: 536 x 395 x 70mm (21.1 x 15.6 x 2.8in), Weight: 6kg (13.2lbs)
