Avitech VCC-8008U Multiviewer

The Avitech VCC-8008U Multiviewer (VCC-8000 Series) is a rackmount multiviewer solution for monitoring multiple DVI-I and HD/SD/Composite video sources on a single display, ideal for broadcast, live production, control rooms, and AV installations where quick visual confirmation of many feeds is required.

These units may show signs of heavy wear but are in good working condition.

Designed for mixed-signal environments, the VCC-8008U accepts both computer and video inputs, making it practical when you need to combine DVI/VGA/YPbPr sources alongside SDI and composite feeds without dedicating a separate monitor to each device.

Signal Support and I/O Flexibility

The VCC-8008U supports 4x DVI/VGA/YPbPr inputs plus 4x CV and HD/SD-SDI inputs. Supported input formats include 480p (60Hz), 576p (50Hz), 720p (50/60Hz), and 1080i (50/60Hz), with DVI-I input resolutions from 640x480 up to 1920x1200.

Display Output Options

DVI-I output resolution options include 800x600, 1024x768, 1280x720, 1280x768, 1280x1024, 1366x768, 1400x1050, 1440x900, 1600x1200, 1680x1050, 1920x1080, and 1920x1200 at 50/60/75Hz, helping you match common control-room displays and professional monitors.

Installation and Control

The unit is built in a metal, 1RU chassis sized for standard 19-inch racks (19” W x 10” D, 48.3cm W x 25.4cm D) and weighs 8 lb (3.6 Kg). PC system requirements listed for setup/control are 256 MB hard disk space and 256 MB RAM, with Windows 98, 2000, XP, or Vista.
